Charvel Pro-Mod Plus DK24-7 HH 2PT EB, Limited Edition, Ebony Fingerboard, Celestial Silk
Description
Pro-Mod Plus Limited Edition DK24-7 HH 2PT EB
The bolt-on caramelized maple “speed” neck
has graphite reinforcement, silky-smooth handrubbed
urethane back finish, heel-mount truss
rod adjustment wheel and Luminlay® side dots.
Its 12”-16” compound radius ebony fingerboard
features comfortable rolled edges, 24 jumbo
stainless steel frets, pearloid dot inlays and Graph
Tech® TUSQ® XL nut.
Brimming with versatility courtesy of the mini twoway
toggle switch for series and parallel, this axe
features an HH pickup configuration consisting
of a direct mount Custom Seymour Duncan®
Full Shred TB-10 bridge pickup and direct mount
Seymour Duncan® Alnico II Pro APH-1N neck
pickup. The bridge pickup radiates a crisp top-end
with low-end articulation, while the neck pickup
has incredible range with soaring highs and silky
lows.
Blending sophisticated style with assertive tone,
the DK24-7 HH 2PT EB also offers premium
modern features such as a five-way blade pickup
switch, speed knobs for the volume (with 500K
EVH® Bourns® low-friction potentiometer) and
no-load tone controls, Gotoh® Custom 510
recessed tremolo bridge, locking tuners, chrome
hardware and more.
Series: Pro-Mod Plus
Body Material: Basswood
Body Finish: Gloss
Neck: Caramelized Maple, Bolt-on
Neck Finish: Natural Satin
Fingerboard: Ebony, 12”-16” Compound Radius (304.8 mm to 406.4 mm)
Frets: 24, Jumbo Stainless Steel
Position Inlays: 4mm Pearloid Dot
Nut (Material/Width): Graph Tech TUSQ XL, 1.875”
Tuning Machines: Charvel®-Branded Die-Cast Locking
Scale Length: 25.5” (64.77 cm)
Bridge: Gotoh® Custom 510 Tremolo
Pickguard: None
Pickups: Seymour Duncan® Full Shred™ TB-10 (Bridge),
Seymour Duncan® Alnico II Pro™ APH-1N (Neck)
Pickup Switching:
5-Position Blade: Position 1. Bridge Pickup, Position 2. Both Outer
Coils, Position 3. Bridge and Neck Pickup, Position 4. Both Inside
Coils, Position 5. Neck Pickup
Auxiliary Switching: 2-Position Mini Toggle Down/All Series, Up/All Parallel
Controls: Volume (500K EVH® Bourns® Low Friction Pot), No-Load Tone
Control Knobs: Speed Knob
Hardware Finish: Chrome
Strings: Nickel Plated Steel (.009-.054 Gauges)
Case/Gig Bag: Included Charvel® Deluxe Gig Bag (P/N 7729019000)
Other Features: Luminlay® Side Dots
| Model: | 2972813576 |
| Manufacturer: | Charvel |
