Aguilar AG700 700W Bass Amp Head

The AG 700 has the clarity, dynamic range and fast transient response of the legendary AG 500 with a big low-end and high headroom. This solid state amplifier provides 700 continuous watts at 4 ohms while only weighing 4.9 lbs. (2.22 kg)!

Boasting an incredibly flexible EQ section, the AG 700 features controls for Treble, High Mid, Low Mid and Bass along with Deep and Bright EQ switches for a broadband boost. The AG 700 also features a series effects loop, XLR balanced output and two rear panel speakon outputs.

AG 700 Features

Power Output:

700 watts @ 2.67 or 4 ohms, 350 watts @ 8 ohms

Preamp Section:

Solid State

Power Section:

Class D

Transformer:

Switching mode power supply (SMPS)

EQ Section:
Bass: +/- 17 dB @ 40 Hz
Deep: +6 dB <250 Hz
Low Mid: +/- 15 dB @ 300 Hz
High Mid: +/- 14dB @ 800 Hz
Treble: +/- 14 dB @ 4 kHz
Bright: +6 dB >3 kHz, shelving

-10dB input pad

Tuner output

Inputs:

One 1/4″ input jack, compatible with all active and passive basses
Speaker Outputs:

Two Neutrik Speakon speaker outputs
Effects Loop:

Series operation. Adds 6 dB of additional gain, making it useful for a broad range of effects units
Balanced Output:

XLR balanced output with pre/post EQ and ground lift switch
Cooling:

Two high-quality whisper fans with thermal speed control
Dimensions:

12″ W x 9″ D x 3″ H
Weight:

4.9 lbs
Warranty:

Three year limited
Optional:

Durable carrying bag MANUAL

Model:	AG700
Manufacturer:	Aguilar
